Lavatory Hoses & Couplings
Aircraft and Jet Lavatory Hoses & Couplings
New Crush Proof Lavatory Dump Hose
Part Number: JACONCPLDH810121520
100% urethane hose wall with urethane tubular helix to protect hose (no wire) * One continuos piece of urethane hose and cuff
* Triple urethane on cuffs for added wear
* UV resistant
* Bending radius 4"
* Temperature resistance -40F, +195F
* Hose colors: see-thru blue, clear (optional)
* Standard lengths: 8', 10', 12', 15' and 20' Other diameters and lengths are available on special request |
 | Lavatory Hoses
Part Number: JACOLH
Lav Hoses with Fabric and Wire |
|
|---|
| Coupling turn-to-lock Open Style Straight Aluminum
Part Number: JACO2653J001P00V |
|
|---|
| Straight Coupling
Part Number: JACO-2653-21-1 |
|
|---|
| Coupling turn-to-lock Open Style Straight Composite
Part Number: JACO2653J001P10V
• Lavatory drain couppling (straight).
• Component materials:
Ballcage-Composite/Aluminum alloy.
Collar-Composite.
Seal-Nitrile.
• A travel stop feature controls collare rotaion and prevents any overriding of the locking balls.
• Nominal pressure rating, 0-5 PSIG.
• Overhaul manual VIM 2651
-64x -64 Lavatory drain Mates and seals with all lavatory drain nipples. Composite collar with cast aluminum 1 piece ballcage. Fitting end-hose connection accpets standard 4" lavatory drain hose. |
|
|---|
| Wye Couplings
Part Number: JACO2651J133P10V , JACO2651J206P10V
Yellow Collar
|
|
|---|
| Wye Coupling
Part Number: JACO2651-133-21-1M
|
|
|---|
| Lav Drain Plug (donut)
Part Number: JACO4259J064S20M
|
|
|---|
| Lav Drain Coupling Nipple Stainless Steel
Part Number: JACO2651-216C00V
|
|
|---|
| Nipple – Parking/ Stowage Point— for all style Lavatory Drain Couplings
Part Number: JACO2651-015A00V
|
|
|---|
| Repair Kit
Part Number: JACO2651-999P01V
Wye Repair Kit
|
|
|---|
| Cam Ring
Part Number: JACO163-XXX1-000
|
|
|---|
| Quad Ring
Part Number: JACO167-XXX1-000
|
|
|---|
| T Handle for a lavatory drain plug extraction
Part Number: JACO2651-X-XX1V
Lavatory drain Not for use when lavatory drain fluid is to be extracted
|
|
|---|
| 4" Drain Cap
Part Number: JACO2651J126AXXV
|
|
|---|
| Dump Valve
Part Number: JACO6401-I
|
|
|---|
| Lavatory Dial Meter
Part Number: JACO620TN
|
|
|---|
| Lavatory Dial Meter
Part Number: JACOIALS96
|
|
|---|
| Lav Hose Parts
Part Number: 167-XXX1-XXX , JACO2651-999PX1V , JACO163-XXX1-XXX |
|
|---|
