Millions of Consumable Products for the Aerospace Industry

3M Motor Lead Pigtail Splice 5318, 5-8 kV, AWG-250 kcmil (feeder), AWG-250 kcmil (motor lead), 1/case

Part Number: 00054007083153 View more details
7000027612 - 3M Motor Lead Pigtail Splice 5318, 5-8 kV, AWG-250 kcmil (feeder), AWG-250 kcmil (motor lead), 1/case

Product Specifications

Unit of Measure
KT
Sold As
Case
Minimum Order Qty
1 KT
Incremental Order Qty
1 KT
Stock Type
Standard
Shelf Life
60 Months
Catalog #
5318
Manufacturer ID
7000027612
UPC
00054007083153
ECCN
EAR99
Manufacturer
3M

Details

Highlights

Designed for use with copper compression, 1 or 2 hole lugs
Has a durable EPDM rubber construction
3M Motor Lead Inline Splicing Kits 5316-5319 Series are designed for splicing motor lead cables to incoming feeder cables, including the accommodation of inline connections at 1000 volts and less. The splice’s main component, the slip on splice cover, is made from EPDM rubber. A mastic strip is used for the moisture seal.3M 5300 Series Motor Lead Pigtail Splice Kit contains 3 each of pigtail lug covers, locking pins, mastic sealing strips, silicone grease tubes, solvent cleaning cloths, splicing tape 130C strips and more. This non shielded splice kit features a slip on splice cover that is made of a durable EPDM rubber while mastic strips are used for moisture seal applications. It includes high dielectric constant stress control for reducing the size and electrical stress. This kit is perfect for splicing polyethylene/cross linked cable, ethylene propylene rubber cable, copper conductors and more. CSA Certified and RoHS 2011/65/EU Compliant .
