Millions of Consumable Products for the Aerospace Industry

3M Scotchcast Re-enterable Electrical Insulating Resin 2123 Easy Dispenser 250, size 250 ml, 6 bags/case

Part Number: 04054596840645 View more details
7100231726 - 3M Scotchcast Re-enterable Electrical Insulating Resin 2123 Easy Dispenser 250, size 250 ml, 6 bags/case

Product Specifications

Unit of Measure
BG
Sold As
Bag
Minimum Order Qty
6 BG
Incremental Order Qty
6 BG
Stock Type
Standard
Catalog #
2123 RESIN EASY DI
Manufacturer ID
7100231726
UPC
04054596840645
ECCN
EAR99
Manufacturer
3M

Details

Highlights

3M Scotchcast Easy Dispenser 250: Compatible and used with commercially available applicator guns
3M Scotchcast Easy Dispenser 250: Mixing of resin components is by a static mixer and delivered together with cartridge
Elongates 300% longer than its original size for easy insulation or wrapping
Excellent wetting properties and low viscosity
Has 62 minute gel time at 23 -¦C (73 -¦F)
High performance re-enterable resin in bag package for sealing and insulating low voltage cables connections in electrical boxes
Rated up to 1 kV
RoHS 2011/65/EU and REACH Compliant
Typical hardness (ASTM D2240) - 0 Shore A
Useful for sealing and electrical insulation in potting applications
Withstands a max temperature in continuous use of 90 -¦C (194 -¦F)
3M Scotchcast Re-Enterable Electrical Insulating Resin 2123 is a soft, two-part polybutadiene resin encapsulant. This resin has good handling and performance characteristics and is formulated for re-enterable splice protection. This multi purpose, moisture sealing resin bonds to nearly all cable jackets.3M Scotchcast Electrical Insulating Resin 2123 has good wetting and low viscosity properties. This soft flexible resin ensures curing at room temperature and acts as an insulating material for cable splices operating up to 1 kV. It flows easily, even at low temperatures, while filling the enclosure and minimizing voids. It is tested according to ASTM, CENELEC HD 623.S1 (EN50393) standard and is 2011/65/EU (RoHS) as well as 1907/2007/EC (REACH) compliant.
