Millions of Consumable Products for the Aerospace Industry

3M Scotchcast Electrical Resin 265, 50 lb, 1/Case

Part Number: 00054007345220 View more details
7000006256 - 3M Scotchcast Electrical Resin 265, 50 lb, 1/Case

Product Specifications

Unit of Measure
LBR
Sold As
Case
Minimum Order Qty
50 LBR
Incremental Order Qty
50 LBR
Package Quantity
50 US pounds per Case
Stock Type
Standard
Shelf Life
730 Days
Catalog #
265
Manufacturer ID
7000006256
UPC
00054007345220
ECCN
EAR99
Manufacturer
3M
View all 4 options in 3M Scotchcast Electrical Resin 265

Details

Highlights

Applied by trickle, spray or dip processes
For a variety of coating, bonding and saturation applications
Has 60-second gel time at 379.4 °F (193 °C)
Provides excellent electrical properties and thermal shock resistance
Solids insulation renders good adhesion, thermal and electrical properties
Withstands temperatures of 356 °F (180 °C)
3M Scotchcast Resin 265 is a 1 part, general purpose, epoxy based, rapid cure, powder resin. It is manufactured by a fusion blend process while ensuring that each particle of powder contains all the components necessary to effect a complete cure and attain stated performance properties. The 100% solid insulation offers enhanced adhesion, thermal and electrical properties.3M Scotchcast Electrical Resin 265 has a low melt viscosity and minimum build that is ideal for a variety of coating, bonding and saturation applications. It is a widely used, well known, general purpose epoxy powder resin. The non flammable resin does not contain any solvents and does not require any mixing or catalyzation. This odor free resin can be applied by trickle, spray or dip processes, and is simply applied to the heated windings where it melts, flows into the wire interstices and cures. ASTM Approved and RoHS 2011/65/EU Compliant.
