Key Features
- User-friendly touch controls w/numeric keypad & easy to read LCD readout
- Accurate Digital Speed Control (using a stepper motor)
- Electronic Temperature Control
- Turbulent Air Flow system for fast processing
- 99 Programs available for storing speeds and temperature
- High Limit Safety Shut Down
- Automatic set points Start-Up / Shut Down Times with choice of days of the week
- Digital Date and Time Clock
SCHEME Technology
SCHEME (Speed Controlled Energy Management Environment)
A proprietary system that automatically varies the speed of the conveyor to compensate for changing temperatures. The result is a constant heat-time product at 100 inches per minute speeds. There is little or no waiting to load the conveyor.
| Operating Temperature Range |
Room temperature to 350°F |
| Conveyor Speed |
1 to 100 inches per minute |
| Oven Opening |
6" height × 12" width |
| Overall Dimensions |
92" × 12" wide (including conveyors)
In-feed conveyor: 27" length
Oven housing: 52" × 36" wide × 18" high |
| Weight |
200 lbs |
| Operating Voltage |
220V |
| Power Requirements |
5000 watts, 20 Amps Single Phase |
| Operating Ambient Temperature |
10 to 40 degrees C |
| Certifications |
CE Listed, FCC Class B Certification |
| Model Number |
AMTI 019-1575W |
| Patents |
Patents Pending |
Optional Accessories
Custom extruded aluminum movable stand - P/N 3361 w/5" dia. locking wheels.
Warranty
Every Shrink Industrial Oven carries a one-year warranty on the electronics and mechanical components (excluding the conveyor belt & bearings).
